STRADA
STRADA
IN THE ZONE
From the start, our goal for the Strada was aerodynamics AND comfort. While pushing the limits of aerodynamics and comfort, the Strada has two clearly distinct zones: Speed zone: the front half of the bike, with its deep yet narrow headtube, wrap-around downtube and bladed fork.
Comfort zone: the curved seattube, slender seatstays and long exposed seatpost provide comfort while also helping aerodynamics.
28-30MM TIRE OPTIMIZATION
Tires provide more compliance than any other part of the bike. Wider tires are better at reducing shocks from cracks, curbs, cobbles and potholes, They even have lower rolling resistance, because their shorter contact patch requires less bending by the casing.
In addition, wide tires reduce fatigue caused by high-frequency road buzz. But aerodynamics are also important on such rides, and the Strada remains the first aero bike engineered around wide tires (just like the Discus wheel range is engineered specifically around wider tires). Finally you can be fast and comfortable all day, every day, with one and the same bike.
REALFAST AERODYNAMICS
We love aerodynamics. Not just the theory, but real world aerodynamics. So we test at 20mph (32kmh) and 30mph (48kmh), we test with bottles and other “difficult parts”, we sometimes even test dirty and muddy bikes.
3T FUNDI INTEGRALE II FORK
The Fundi Integrale II fork has been developed with deep and thin asymmetric fork blades to deliver the best possible aero features including great brake integration and very smooth transition from the fork crown to the frame. Unparallel handling features complete the package.
3T INTEGRALE AERO CABLE INTEGRATION
Running cables internally can be nice and potentially reduce aero drag, but what is the point if you end up with a very wide and bulky headtube with oversized bearings to house the cables?
Our goal was to hide the cables but keep the headtube narrow. Quite the puzzle but the result is stunning. In the front view you will see our bearings are still narrow and the headtube even thins down in-between them. In the side view, you’ll see the headtube is deep and with a full aero “nose”.
To top it off, the cables hide inside the 3T Apto Integrale, using the original minimalist Apto shape but with cable guidance. Beauty meets functionality as this gives you full adjustability to find the perfect fit. Because aerodynamics are meaningless if you cannot stay comfortably in your aero position. 3T Strada is compatible with SRAM and Shimano electronic drivetrains, both 2x and 1x.
For more information see MANUAL
design in details
MINIMALIST CROWN
Instead of a bulky, unaero crown, we minimize its size. This improves the crown’s aerodynamics and moves the front wheel closer to the downtube, creating a perfect transition for the airflow.
CONTINUOUS FIBER CROWN
The integrated carbon bearing race uses a separate ring layup (green), so fibers in the fork crown run more straight from the legs into the steerer for a strong and stiff connection.
SQAERO FORK LEGS
The Sqaero fork airfoil only has a small truncation, perfect to guide the airflow around the front wheel and boost fork stiffness. Different left & right profiles are used to counteract braking forces.
MAXIMIZED CURVED CUT-OUT
The curved seattube covers more of the rear wheel and provides extra comfort.
MIND THE GAP
The downtube closely follows the front wheel for better airflow transition and less turbulence.
32MM DOWNTUBE NECK
In front of the water bottle, the downtube narrows to perfectly match the front tire airflow.
NARROW & DEEP HEADTUBE
Narrow (1.125"-1.25" cups instead of common 1.5" for internal cable routing) is aero. Deep guides the airflow. All cables inside.
BIG STEERER
Inside the narrow headtube is a steerer with a large 1.5” lower section for best strength and stiffness.
3T MINMAX INTEGRALE HEADSET
To fit this big 1.5" steerer inside the narrow 1.125"-1.25" headtube cups, we use this custom ultra-sleek high-load headset.
TIRE CLEARANCE
Fits tires up to 30mm WAM and 344mm RAM.
THREADED BB
All Strada complete bikes come with threaded BBs without any alloy rings in the carbon (added weight, complexity and debonding risk).
DIRECT-MOUNT FRONT BRAKE
Standard forks require a flip-flop adaptor to set the correct brake rotor size. Our direct-mount pre-sets the caliper for 160mm rotors without any extra pieces.
SELF-ALIGNING WEDGE CLAMP
Self-adjusting bolt angle for higher clamping forces with lower torque.
RITCHEY RAIL CLAMP
The new standard for road bikes, available for round and oval rails.
frame specifications
for frame specifications, component compatibility, clearances, etc, please check our Strada MY2025
Frameset Specifications. Geometry information is found below
GEOMETRIES
* Rider heights are approximations. For more accuracy, compare stack/reach with your current bike or visit your 3T retailer.
** Note that most saddles add an additional 40mm from the rail to the top of the deck. shown here is the maximum height to the rail, achieved with the standard seatpost for that size. You can order longer seatposts here if you require a higher saddle position.
| Size | XXS | 51 | 54 | 56 | 58 |
|---|---|---|---|---|---|
| Rider Height (cm) | 150-163 | 157-170 | 168-180 | 178-191 | 188-201 |
| Rider Height* (inches) | 4'9"-5'4" | 5'2"-5'7" | 5'6"-5'11" | 5'10"-6'3" | 6'2"-6'7" |
| Stack | 501 | 507 | 536 | 565 | 594 |
| Reach | 349 | 369 | 381 | 393 | 405 |
| Fork axle-crown | 355 | 355 | 355 | 355 | 355 |
| Front center | 567 | 574 | 580 | 596 | 616 |
| Rear center | 405 | 405 | 405 | 405 | 405 |
| BB drop | 69 | 69 | 69 | 69 | 69 |
| Headtube lenght | 119 | 119 | 143 | 172 | 202 |
| Toptube lenght | 507 | 529 | 550 | 571 | 592 |
| Seattube lenght | 487 | 500 | 506 | 518 | 533 |
| Seattube angle | 72.5 | 72.5 | 72.5 | 72.5 | 72.5 |
| Headtube angle | 69.5 | 71.0 | 72.7 | 73.2 | 73.2 |
